TNG® Seal Since 1982

Offers all kinds of replacement Mechanical seals for John Crane,Burgmann,Flowserve,Roten,Chesterton, AESSEAL, LATTY, ITT,Xylem,Flygt pump seals,Grundfos pump seals.

Elastomer Bellows mechanical seal
Elastomer Bellows mechanical seal

Elastomer bellows mechanical seal is indentified by the use of an elastomer bellows or diaphragm for the secondary sealing member. Elatomer bellows seal units require a positive abutment at the back of the bellows or spring, positioned so as to give the correct seal working length

O-ring Pusher Mechanical seals
O-ring Pusher Mechanical seals

O-ring Pusher seals use a sliding secondary seal and in this design the O-ring is pushed along the outside diameter of the equipment shaft or sleeve. The O-ring retains the sealed liquid and follows along the shaft to compensate for face wear.

PTFE Bellows Mechanical seals
PTFE Bellows Mechanical seals

Type 10T and 10R both use PTFE bellows, and are designed for external mounting on extremely corrosive duties including acids, salts and organic compounds.

Metal Bellows Mechanical seals
Metal Bellows Mechanical seals

Metal Bellows seal are constructed by welding a series of diaphragms together to form a bellows units. Metal bellows seals are often effective in a wide range of other seal applications. The most common of these is chemical, general water pump applications

Grundfos Pump seal
Grundfos Pump seal

TNG® Seal involve in mechanical seals designing, manufacturing since 1982.we can provide all kinds of Brand Pump seals,such as GRUNDFOS® pump,ALFA LAVAL® sanitary pump,Flygt Pump....and our seal is totally conform to EN12576 standard.

About UsRead More

Wenzhou Tiangu Seal Co., Ltd has been designing and producing Mechanical Seals Since 1982.
TNG Seal is the member of China Hydraulic Pressure Pneumatic Mechanical Seal Industry Academician. We are specialists in the design and manufacture of mechanical seals used in pumps and rotating equipments.
In the past few decades, Within continuous explorations, accumulating and design. We have developed Elastomer O-ring & PTFE Wedge mechanical seals, Elastomer bellows mechanical seals, Inaction mechanical seals, Double face mechanical seals, Metal bellows mechanical seals...

  • Burgmann MG1/MG12/MG13 replacement seal

    TG109 series is the most common rubber bellows mechanical seals allow for fast and easy installation. it is also be used as multiple seal in tandem mechanical seals in two sets arrangement. Mechanical Seal Type TG109 is widely used in Chemical standard pumps, screw pumps, slurry pumps and Petroleum chemical industry

  • Mechanical seal patent Certification(CN101696728A)

    In order to overcome the pump mechanical seal with liquid technology deficiencies exist, especially poor seal resistance to deformation, the carrying capacity of the liquid film in general (dynamic pressure effect is not strong), pressure poor performance, high-parameter condition Under a large amount of leakage is less than the present invention provides a cross-scale surface texture characteristics of liquid lubrication seal structure.
